Pneumatic system / valves

Brake actuator

23.048.32971
MERCEDES - ATEGO I, ATEGO II Brake type: Disk brake Connection ports thread: M22x1,5 Diaphragm type: 16/24 Mounting thread: M16x1.5 Output force, N: 8290 Springiness, N: 220
23.048.33273
MAN - TGA
23.048.33287
MERCEDES RENAULT
23.048.33516
MERCEDES - ACTROS III, ACTROS II, AXOR II Brake type: Drum brake Connection ports thread: M22x1,5 Diaphragm type: 16/24 Max. operating pressure, bar: 8,0/8,0 Output force, N: 7900 Side: Left
23.048.33979
MERCEDES - ATEGO I, ATEGO II, ATEGO III Brake type: Disk brake Connection ports thread: M22x1,5 Diaphragm type: 16/24 Mounting thread: M16x1.5 Stroke, mm: 57
23.048.34123
DAF SCANIA - Series 3, Series 4, Series 5 (P/G/R/T), BUS Brake type: Drum brake Diaphragm type: 20/24 Max. operating pressure, bar: 10,5/8,5 Output force, N: 8800 Springiness, N: 220 Stroke, mm: 65
23.048.34665
MERCEDES - O300 Brake type: Disk brake Diaphragm type: 16/24 Max. operating pressure, bar: 8,0/8,0 Output force, N: 6400 Springiness, N: 220 Stroke, mm: 53
